NODO track has been studied to integrate the optional LED light easily and hidden from view.
MICROLED is dimmable and available in 3000K version.
When the track is suspended from the ceiling, the LED light is in a Up Light position for indirect ambient lighting.
When the track is fixed on a horizontal or vertical surface, the LED light is placed in the Side Light position for diffused lighting on the surface.
NODO MICROLED
NODO MICROLED
Not dimmable power supply
Dimmer – Mono PWM
[0-10V, 1-10V, Push, POT, DALI]
180 LED/m – 11W -24V
100cm – 3000K – 1100 lm/m
63010 Silver
200cm – 3000K – 1100 lm/m
63020 Silver
300cm – 3000K – 1100 lm/m
63030 Silver
25120 70W
25125 150W
INPUT 220/240V AC 50/60 Hz
OUTPUT 24V – 70W / 150W
40209 Dimmer
INPUT 24V DC OUTPUT 24V DC
Optional
25162 CASAMBI Dimmer
25160 CASAMBI Remote control
The Casambi 25162 device, combined with 40209, allows the installation to be controlled via Bluetooth.
Special sizes upon request.
Aluminium dimmable LED profile.
Attachment to the track using the integrated double sided tape.
The electric installation is independent from the system.
Constant voltage power supply.
Not dimmable.
Combined with dimmer 40209 it allows dimming of the LED bar. It must be housed remotely from the installation.
Single-channel dimmer with PWM voltage output.
Control inputs: isolated button, DALI, isolated boost (100K), passive 0-10V (not insulated), passive 1-10V (not insulated).
Kg 0.10 / 100cm
Kg 0.30
Kg 0.15
NODO MICROLED
180 LED/m – 11W -24V
100cm – 3000K – 1100 lm/m
63010 Silver
200cm – 3000K – 1100 lm/m
63020 Silver
300cm – 3000K – 1100 lm/m
63030 Silver
Special sizes upon request.
Aluminium dimmable LED profile.
Attachment to the track using the integrated double sided tape.
The electric installation is independent from the system.
Download
Kg 0.10 / 100cm
Not dimmable power supply
25120 70W
25125 150W
INPUT 220/240V AC 50/60 Hz
OUTPUT 24V – 70W / 150W
Constant voltage power supply.
Not dimmable.
Combined with dimmer 40209 it allows dimming of the LED bar. It must be housed remotely from the installation.
Download
Kg 0.30
Dimmer – Mono PWM
[0-10V, 1-10V, Push, POT, DALI]
40209 Dimmer
INPUT 24V DC OUTPUT 24V DC
Optional
25162 CASAMBI Dimmer
25160 CASAMBI Remote control
The Casambi 25162 device, combined with 40209, allows the installation to be controlled via Bluetooth.
Single-channel dimmer with PWM voltage output.
Control inputs: isolated button, DALI, isolated boost (100K), passive 0-10V (not insulated), passive 1-10V (not insulated).
Download
Kg 0.15
